Cisco Systems® offers a complete range of antennas for access point and bridge
equipment that enable a customized wireless solution for almost any installation.
Every wireless LAN deployment is different. When engineering an in-building solution,
varying facility sizes, construction materials, and interior divisions raise transmission
and multipath considerations. When implementing a building-to-building solution,
distance, physical obstructions between facilities, and number of transmission points
must be taken into account. Cisco offers a complete range of 2.4 GHz and 5 GHz antennas
for access point and bridge equipment that enable a customized wireless solution
for almost any installation. With the Cisco FCC-approved directional and omnidirectional
antennas, low-loss cable, mounting hardware, and other accessories, we can
customize a wireless solution that meets the requirements of even the most
challenging applications. Want to know more about antennas?
Download the Cisco Antenna Reference Guide (1.98MB PDF). Want a complete
listing of the Cisco Antennas and Accessories?
Download the Cisco Antennas and Accessories Data Sheet (298KB PDF).
Cisco Aironet 2.4-GHz access point antennas are compatible with all Cisco RP-TNC-equipped
access points. The antennas are available with different gain and range capabilities,
beam widths, and form factors. Coupling the appropriate antenna and access point
allows for efficient coverage in any facility, as well as better reliability at
higher data rates (Table 1).
Cisco Aironet 5 GHz access point antennas have RP-TNC connectors and are compatible
with Cisco Aironet 1200 Series and 1230AG Series access points when equipped with
a RM22A radio module. Selection of the appropriate antenna should provide optimal
coverage for the desired application in the 5 GHz frequency band (Table 2).
Cisco Dual Band Antenna for 2.4 GHz and 5 GHz Access Points Cisco offers a dual
band antenna, or a radome which has both 2.4 GHz and 5 GHz elements in one low profile
package. The antenna has 4 cables, two for 2.4 GHz and 2 for 5 GHz, color coded
to prevent any accidental connections. Easy to install and lightweight, this antenna
is ideal for indoor wall or ceiling mount applications (Table 3).
The Cisco Aironet 1250 Series Access Points feature multiple-input and multiple-output
(MIMO) technology. These access points have 6 connectors or 3 connectors for 2.4
GHz and 3 connectors for 5 GHz. Cisco has developed antennas specifically for use
with the Cisco Aironet 1250 Series Access Points but most existing antennas can
also be used (Table 4).
Cisco Aironet bridge antennas allow for extraordinary transmission distances between
two or more buildings. Available in directional configurations for point-to-point
transmission and omnidirectional configuration for point-to-multipoint implementations,
Cisco has a bridge antenna for every application. Cisco Aironet 2.4 GHz Access Point
and Bridge Antennas with RP-TNC Connectors for Cisco Aironet 1200 and
1300 Series products are shown in Table 5.
The antennas with N-Type Connectors for use with the Cisco Aironet 1400 Series 802.11a
Wireless Bridge are shown in Table 6.
Cisco offers 2.4 GHz and 5 GHz Antennas with N-Type Connectors for the Cisco Aironet
1500 Series Lightweight Outdoor Mesh Access Points in various gains and antenna
types. (Table 7).
Table 1. Cisco Aironet 2.4 GHz Access Point Antennas with RP-TNC Connectors
| AIR-ANT5959Description: Diversity omnidirectional ceiling mount
Application: Indoor unobtrusive antenna, best for ceiling mount; excellent throughput and coverage solution in high multipath cells and dense user population
Gain: Two separate 2-dBi omnidirectional elements; minimum gain of 2.0, maximum gain of 2.35
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 295 ft (90 m)
Approximate Indoor Range at 54 Mbps*: 88 ft (27 m)
Beam Width: 360°H, 80°V
Cable Length: 3 ft (0.91 m)**
Dimensions: 5.3 x 2.8 x 0.9 in. (13.5 x 7.1 x 2.3 cm)
Weight: 7 oz (0.19 kg)
Operating Temperature: 0° to +55°C |
| AIR-ANT3213 Description: Pillar mount diversity omnidirectional
Application: Indoor, unobtrusive midrange antenna
Gain: 5.2 dBi with two radiating elements
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 379 ft (121 m)
Approximate Indoor Range at 54 Mbps*: 114 ft (35 m)
Beam Width: 360°H, 25°V
Cable Length: 3 ft (0.91 m)
Dimensions: 14 x 5 x 1 in. (35.5 x 12.7 x 2.5 cm)
Weight: 1 lb (0.45 kg)
Operating Temperature: 0° to +70°C |
| AIR-ANT2410Y-R Description: Yagi mast or wall mount
Application: Indoor/outdoor directional antenna for use with access points or bridges
Gain: 10 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 548 ft (167 m)
Approximate Indoor Range at 54 Mbps*: 165 ft (50 m)
Beam Width: 55°H, 47°V
Cable Length: 3 ft (0.91 m)
Dimensions: 7.25 x 3 in. (18.4 x 7.62 cm)
Weight: 8 oz (0.23 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT1728 Description: Omnidirectional ceiling mount
Application: Indoor midrange antenna, typically hung from crossbars of drop ceilings
Gain: 5.2 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 379 ft (116 m)
Approximate Indoor Range at 54 Mbps*: 114 ft (35 m)
Beam Width: 360°H, 36°V
Cable Length: 3 ft (0.91 m)
Dimensions: Length: 11.25 in. (28.5 cm) Diameter: 1 in. (2.5 cm)
Weight: 4.6 oz (0.13 kg)
Operating Temperature: 0° to +55°C |
| AIR-ANT4941 Description: 2.2-dBi black dipole antenna
Application: Indoor omnidirectional coverage
Gain: 2.2 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 300 ft (91 m)
Approximate Indoor Range at 54 Mbps*: 90 ft (27 m)
Beam Width: 360°H, 65°V
Cable Length: None
Dimensions: 5.5 in. (14 cm)
Weight: 1.1 oz (31 g)
Operating Temperature: 0° to +55°C |
| AIR-ANT2422DG-R Description: 2.2 dBi gray non-articulating dipole antenna
Application: Indoor omnidirectional coverage
Gain: 2.2 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 300 ft (91 m)
Approximate Indoor Range at 54 Mbps*: 90 ft (27 m)
Beam Width: 360°H, 65°V
Cable Length: None
Dimensions: 3.9 in (9.9 cm)
Weight: 1.1 oz (31 g)
Operating Temperature: 0° to +55°C |
| AIR-ANT2422DW-R Description: 2.2-dBi white dipole antenna
Application: Indoor omnidirectional coverage
Gain: 2.2 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 300 ft (91 m)
Approximate Indoor Range at 54 Mbps*: 90 ft (27 m)
Beam Width: 360°H, 65°V
Cable Length: None
Dimensions: 5.5 in. (14 cm)
Weight: 1.1 oz (31 g)
Operating Temperature: 0° to +55°C |
| AIR-ANT2485P-R Description: Patch wall mount
Application: Indoor/outdoor, unobtrusive, long-range antenna (may also be used as a midrange bridge antenna)
Gain: 8.5 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 507 ft (155 m)
Approximate Indoor Range at 54 Mbps*: 153 ft (47 m)
Beam Width: 66°H, 56°V
Cable Length: 3 ft (0.91 m)
Dimensions: 5.3 x 5.3 x .90 in. (13.5 x 13.5 x 2.28 cm)
Weight: 8.2 oz (0.23 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT2460P-R Description: Patch wall mount
Application: Indoor/outdoor, unobtrusive, midrange antenna (may also be used as a midrange bridge antenna)
Gain: 6 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 403 ft (123 m)
Approximate Indoor Range at 54 Mbps*: 121 ft (37 m)
Beam Width: 75°H, 73°V
Cable Length: 3 ft (0.91 m)
Dimensions: 4.1 x 3.9 x .75 in. (10.4 x 9.9 x 1.9 cm)
Weight: 6 oz (0.17 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT2450S-R Description: Wall Mount sector
Application: Indoor, outdoor, midrange, sector antenna (may be used as a midrange bridge antenna
Gain: 5 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 379 ft (116 m)
Approximate Indoor Range at 54 Mbps*: 114 ft (35 m)
Beam Width: 135°H, 54°V
Cable Length: 3 ft (0.91 m) **
Dimensions: 6 x 3 x 2 in (15.2 x 7.6 x 5 cm)
Weight: 7 oz ( 0.2 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT2465P-R Description: Diversity patch wall mount
Application: Indoor/outdoor, unobtrusive midrange antenna
Gain: 6.5 dBi with two radiating elements
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 418 ft (127 m)
Approximate Indoor Range at 54 Mbps*: 126 ft (38 m)
Beam Width: 75°H, 57°V
Cable Length: 3 ft (0.91 m)**
Dimensions: 5 x 6.7 x .90 in. (12.7 x 17 x 2.28 cm)
Weight: 11.6 oz (0.33 kg)
Operating Temperature: -30° to +70°C |
* All range estimations are based on an external antenna associating with an integrated Intel Centrino client adapter under ideal
conditions. The distances referenced here are approximations and should be used for estimation purposes only.
** The cable provided on noted antennas meets UL 2043 certification for plenum rating requirements set by local fire codes and
supports installation in environmental air spaces such as areas above suspended ceilings.
Table 2. Cisco Aironet 5 GHz Access Point Antennas with RP-TNC Connectors
| AIR-ANT5135D-R Description: 3.5-dBi black dipole antenna
Application: Indoor omnidirectional coverage
Gain: 3.5 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 675 ft (206 m)
Approximate Indoor Range at 54 Mbps*: 75 ft (21 m)
Beam Width: 360°H, 40°E
Cable Length: None
Dimensions: 5.3 x 0.6 in. (13.5 x 1.5 cm)
Weight: 1 oz (28.3 g)
Operating Temperature: 0° to +55°C |
|
AIR-ANT5135DG-R**** Description: 3.5 dBi gray non-articulating dipole antenna
Application: Indoor omnidirectional
Gain: 3.5 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 675 ft (206 m)
Approximate Indoor Range at 54 Mbps*: 75 ft (21 m)
Beam Width: 360°H, 40°E
Cable Length: None
Dimensions: 3.61 x .06 in (9.2 x 1.5 cm)
Weight: 1 oz (28.3 g)
Operating Temperature: 0° to +55°C |
| AIR-ANT5135DW-R Description: 3.5-dBi white dipole antenna
Application: Indoor omnidirectional coverage
Gain: 3.5 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 675 ft (206 m)
Approximate Indoor Range at 54 Mbps*: 75 ft (21 m)
Beam Width: 360°H, 40°E
Cable Length: None
Dimensions: 5.3 x 0.6 in. (13.5 x 1.5 cm)
Weight: 1 oz (28.3 g)
Operating Temperature: 0° to +55°C |
* All range estimations are based on an external antenna associating with an integrated Intel Centrino client under ideal conditions. The distances referenced here are approximations and should be used for estimation purposes only. ** The cable provided on noted antennas meets UL 2043 certification for plenum rating requirements set by local fire codes and supports installation in environmental air spaces such as areas above suspended ceilings. *** 5 GHz antennas are denoted by either a blue dot on the radome or blue marker on the cable near the connector. **** Best suited for use on the Cisco Aironet 1250 Series Access Point but can also be used on other access points with RP-TNC connectors.
Table 3. Cisco Dual Band Antenna for 2.4 GHz and 5 GHz Access Points
| AIR-ANT2451V-R= Description: Dual band: 2 dBi in 2.4 GHz and 3dBi in 5 GHz omnidirectional ceiling mount
Application: Indoor midrange antenna
Gain: 2 dBi in 2.4 GHz 3 dBi in 5 GHz
Frequency: 2.4 and 5 GHz
Approximate Indoor Range at 6 Mbps**: 2.4 GHz: 295 ft (90 m) 5 GHz: 675 ft (206 m)
Approximate Indoor Range at 54 Mbps**: 2.4 GHz: 88 ft (27 m) 5 GHz: 75 ft (21 m)
Beam Width: 2.4GHz: 360°H, 80°E 5 GHz: 360°H, 50°E
Cable Length: 18 in (45.7 cm)
Dimensions: 8.5 in. x 6 in. x .93 in (21.5 cm x 15.2 cm x 2.4cm)
Weight: 1 lb (4.5 kg)
Operating Temperature: 0° to +55°C |
*5 GHz antennas are denoted by either a blue dot on the radome or blue marker on the cable near the connector. ** All range estimations are based on an external antenna associating with an integrated Intel Centrino client adapter under ideal conditions. The distances referenced here are approximations and should be used for estimation purposes only.
Table 4. 2.4 GHz And 5 GHz Access Point Antennas with RP-TNC Connectors for Cisco Aironet 1250 Series Access Points
| AIR-ANT2430V-R Description: Ceiling mount omnidirectional
Application: Indoor carpeted area type, unobtrusive omnidirectional antennas for Cisco Aironet 1250 Series MIMO Radios
Gain: 3.0 dBi
Frequency: 2.4 GHz
Approximate Indoor Range at 6 Mbps*: 507 ft (155 m)
Approximate Indoor Range at 54 Mbps*: 153 ft (47 m)
Beam Width: 360°H, 60°V
Cable Length: 3 ft (0.91 m) 3 cables with RP-TNC
Dimensions: 12.1 x 4.2 x 1.6 in. (30.73 x 10.67 x 4.06 cm)
Weight: 27 oz (0.76 kg)
Operating Temperature: 0° to +55°C |
| AIR-ANT5140V-R Description: Ceiling mount omnidirectional
Application: Indoor carpeted area type, unobtrusive omnidirectional antennas for Cisco Aironet 1250 Series MIMO Radios
Gain: 4.0 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 403 ft (123 m)
Approximate Indoor Range at 54 Mbps*: 121 ft (37 m)
Beam Width: 360°H, 45°V
Cable Length: 3 ft (0.91 m) 3 cables with RP-TNC
Dimensions: 6.9 x 3 x .9 in (17.53 x 7.62 x 2.29 cm)
Weight: 14.1 oz (0.40 kg)
Operating Temperature: 0° to +55°C |
| AIR-ANT2451V-R= Description: Dual band: 2 dBi in 2.4 GHz and 3dBi in 5 GHz omnidirectional ceiling mount
Application: Indoor midrange antenna
Gain: 2 dBi in 2.4 GHz 3 dBi in 5 GHz
Frequency***: 2.4 and 5 GHz
Approximate Indoor Range at 6 Mbps*: 2.4 GHz: 295 ft (90 m) 5 GHz: 675 ft (206 m)
Approximate Indoor Range at 54 Mbps*: 2.4 GHz: 88 ft (27 m) 5 GHz: 75 ft (21 m)
Beam Width: 2.4GHz: 360°H, 80°E 5 GHz: 360°H, 50°E
Cable Length: 18 in (45.7 cm)
Dimensions: 8.5 in. x 6 in. x .93 in (21.5 cm x 15.2 cm x 2.4cm)
Weight: 1 lb (4.5 kg)
Operating Temperature: 0° to +55°C |
| AIR-ANT5145V-R Description: 4.5-dBi diversity omnidirectional ceiling mount
Application: Indoor midrange antenna
Gain: 4.5 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 732 ft (223 m)
Approximate Indoor Range at 54 Mbps*: 82 ft (25 m)
Beam Width: 360°H, 50°E
Cable Length: 3 ft (0.91 m)
Dimensions: 6.75 x 4.1 in. (17.1 x 10.4 cm)
Weight: 11.5 oz (0.33 kg)
Operating Temperature: 0° to +55°C |
| AIR-ANT5160V-R Description: 6 dBi omnidirectional antenna
Application: Indoor/outdoor midrange antenna
Gain: 6 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 822 ft (251 m)
Approximate Indoor Range at 54 Mbps*: 92 ft (28 m)
Beam Width: 360°H, 17°E
Cable Length: 3 ft (0.91 m)
Dimensions: 12 in. length; 1 in. diameter (30.5 x 2.5 cm)
Weight: 5.3 oz (0.15 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT5170P-R Description: Diversity patch wall mount
Application: Indoor/outdoor directional wall mount antenna
Gain: 7.0 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 880 ft (270 m)
Approximate Indoor Range at 54 Mbps*: 140 ft (43 m)
Beam Width: 70° H, 50° V
Cable Length: 3 ft (0.91 m)
Dimensions: 5.7 in. (14.5 cm) x 4.3 in. (10.9 cm) x 0.7 in. (1.8 cm)
Weight: 8 oz (0.2 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT5195P-R Description: Patch wall or articulating mast mount
Application: Indoor/outdoor patch antenna provides different mounting options
Gain: 9.5 dBi
Frequency***: 5 GHz
Approximate Indoor Range at 6 Mbps*: 1030 ft (313 m)
Approximate Indoor Range at 54 Mbps*: 170 ft (52 m)
Beam Width: 50° H, 43° V
Cable Length: 3 ft (0.91 m)
Dimensions: 5.1 in. (12.9 cm) x 5.1 in. (12.9 cm) x 1.0 in. (2.5 cm)
Weight: 9 oz. (0.25 kg)
Operating Temperature: -30° to + |
* All range estimations are based on an external antenna associating with an integrated Intel Centrino client adapter under ideal conditions. The distances referenced here are approximations and should be used for estimation purposes only. ** The cable provided on noted antennas meets UL 2043 certification for plenum rating requirements set by local fire codes and supports installation in environmental air spaces such as areas above suspended ceilings. *** 5 GHz antennas are denoted by either a blue dot on the radome or blue marker on the cable near the connector.
Table 5. Cisco Aironet 2.4 GHz Access Point and Bridge Antennas with RP-TNC Connectors for Cisco Aironet 1200
and 1300 Series products
| AIR-ANT2506 Description: Omnidirectional mast mount
Application: Outdoor short-range point-to-multipoint applications
Gain: 5.2 dBi
Frequency: 2.4 GHz
Approximate Range at 2 Mbps*: 3.3 miles (5.31 km)
Approximate Range at 11 Mbps*: 1.66 miles (2.66 km)
Approximate Range at 54 Mbps*: .21 miles (.34 km)
Beam Width: 360°H, 36°V
Cable Length: 3 ft (0.91 m)
Dimensions: Length: 11.5 in. (29.2 cm) Diameter: 1 in. (2.5 cm)
Weight: 5 oz (0.14 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT24120 Description: High-gain omnidirectional mast mount
Application: Outdoor midrange point-to-multipoint applications
Gain: 12 dBi
Frequency: 2.4 GHz
Approximate Range at 2 Mbps*: 15.81 miles (25.43 km)
Approximate Range at 11 Mbps*: 7.92 miles (12.75 km)
Approximate Range at 54 Mbps*: 1.0 miles (1.6 km)
Beam Width: 360°H, 7°V
Cable Length: 1 ft (0.30 m)
Dimensions: Length: 42 in. (107 cm) Diameter: 1.25 in. (3.1 cm)
Weight: 1.5 lb (0.68 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT2414S-R Description: Vertically polarized sector
Application: Outdoor long range point-to-multipoint applications
Gain: 14 dBi
Frequency: 2.4 GHz
Approximate Range at 2 Mbps*: 16.71 miles (26.89 km)
Approximate Range at 11 Mbps*: 8.89 miles (14.30 km)
Approximate Range at 54 Mbps*: 1.26 miles (2.02 km)
Beam Width: 90°H, 8.5°V
Cable Length: 5 ft (1.5m)
Dimensions: Length: 36 in. (91 cm) Width: 6 in. (15 cm) Depth: 4 in. (10 cm)
Weight: 6.5 lb (3 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT1949 Description: Yagi mast mount
Application: Outdoor midrange directional connections
Gain: 13.5 dBi
Frequency: 2.4 GHz
Approximate Range at 2 Mbps*: 18.33 miles (29.49 km)
Approximate Range at 11 Mbps*: 11.19 miles (18.01 km)
Approximate Range at 54 Mbps*: 1.41 miles (2.27 km)
Beam Width: 30°H, 25°V
Cable Length: 3 ft (0.91 m)
Dimensions: Length: 18 in. (46 cm) Diameter: 3 in. (7.6 cm)
Weight: 12 oz (34 kg)
Operating Temperature: -30° to +70°C |
| AIR-ANT3338 Description: Solid dish antenna
Application: Outdoor long-range directional connections
Gain: 21 dBi
Frequency: 2.4 GHz
Approximate Range at 2 Mbps*: 26.49 miles (42.62 km)
Approximate Range at 11 Mbps*: 20.1 miles (32.33 km)
Approximate Range at 54 Mbps*: 4.46 miles (7.17 km)
Beam Width: 12°H, 12°V
Cable Length: 2 ft (0.61 m)
Dimensions: Diameter 24 in. (61 cm)
Weight: 11 lb (5 kg)
Operating Temperature: -30° to +70°C |
* All range estimations are based on use of a BR 1310 access point and the same type of antenna at each end of the connection under ideal
outdoor conditions. The distances referenced here are approximations and should be used for estimation purposes only.
Table 6. Cisco Aironet 5.8 GHz Bridge Antennas with N-Type Connectors for Cisco Aironet 1400 Series Bridges
| AIR-ANT58G9VOA-N Description: Omnidirectional mast mount
Application: Outdoor short-range point-to-multipoint applications
Gain: 9.0 dBi
Frequency: 5.8 GHz
Polarization: Vertical
Elevation Adjustment: None
Approximate Range at 9 Mbps*: 8 miles (13 km) (with 22.5 dBi captive antenna on the remote site)
Approximate Range at 54 Mbps: 2 miles (3 km) (with 22.5 dBi captive antenna on the remote site)
Beam Width: 360° H, 6° V
Supplied Jumper Cable Length: 4.9 ft. (1.5 m)
Dimensions: Length: 20.25 in. (51.4 cm) Diameter: .64 in. (1.62 cm)
Weight: 2.0 lb. (0.9 kg)
Operating Temperature: -20° to +60°C |
| AIR-ANT58G10SSA-N Description: Sector antenna, mast mount
Application: Outdoor medium-range point-to-point and point-to-multipoint applications
Gain: 9.5 dBi
Frequency: 5.8 GHz
Polarization: Vertical or horizontal Field configurable
Elevation Adjustment: None
Approximate Range at 9 Mbps*: 8 miles (13 km) (with 22.5 dBi captive antenna on the remote site)
Approximate Range at 54 Mbps: 2 miles (3 km) (with 22.5 dBi captive antenna on the remote site)
Beam Width: 60° H, 60° V
Supplied Jumper Cable Length: 4.9 ft. (1.5 m)
Dimensions: Length: 2.5 in. (6.4 cm) Width: 2.5 in. (6.4 cm) Depth: 1.75 in. (4.5 cm)
Weight: 1.25 lb. (0.6 kg)
Operating Temperature: -20° to +60°C |
| AIR-ANT58G28SDA-N Description: Dish antenna, mast mount
Application: Outdoor long-range directional connections
Gain: 28.0 dBi
Frequency: 5.8 GHz
Polarization: Vertical or horizontal Field configurable
Elevation Adjustment: +/- 12.5 degrees
Approximate Range at 9 Mbps*: 23 miles (37 km) (with 28 dBi antennas on each end)
Approximate Range at 54 Mbps: 12 miles (19 km) (with 28 dBi antennas on each end)
Beam Width: 4.75°H, 4.75°V
Supplied Jumper Cable Length: 4.9 ft. (1.5 m)
Dimensions: Diameter: 29 in. (74 cm) Depth: 14.5 in. (36.8 cm)
Weight: 9.5 lb. (4.3 kg)
Operating Temperature: -30° to +60°C |
Table 7. Cisco Aironet 2.4 GHz and 4.9-5 GHz Access Point Antennas with N-Type Connectors for Cisco Aironet 1500 Series
Lightweight Outdoor Mesh Access Points. Cisco Aironet 1500 Series Access Points are available in single-band (2.4 GHz) and dual-band
(2.4 GHz and 5 GHz) versions. Check your access point for proper antenna selection before placing an order.
| AIR-ANT2450V-N Description: 5 dBi, direct mount omnidirectional antenna for 2.4 GHz
Application: Omnidirectional antenna for outdoor mesh access points. Suitable for all access point deployments, specifically for cable strand mount applications
Gain: 5 dBi
Frequency: 2.4 GHz
Beam Width: 30° V
Cable Length: None
Dimensions: 11 in. x 1 in. (27.94 x 2.54 cm)
Weight: 0.40 lbs. (0.18 kg)
Operating Temperature: -30° to +70 C |
| AIR-ANT2455V-N Description: 5.5 dBi, direct mount omnidirectional antenna for 2.4 GHz
Application: Omnidirectional antenna suitable for use on Cisco Aironet 1500 Series Lightweight Outdoor Mesh Access Points in all deployments. Not suitable for use on Cisco Aironet 1500 Series Lightweight Outdoor Mesh Access Points in cable strand mount situations.
Gain: 5.5 dBi
Frequency: 2.4 GHz
Beam Width: 25° V
Cable Length: None
Dimensions: 12.5 in. x 1 in. (31.75 x 2.54 cm)
Weight: 0.31 lbs. (0.14 kg)
Operating Temperature: -30° to +70 C |
| AIR-ANT2480V-N Description: 8 dBi direct mount omnidirectional antenna for 2.4 GHz
Application: Extended range omnidirectional antenna for outdoor mesh access points. Suitable for pole or roof mounting deployments.
Gain: 8 dBi
Frequency: 2.4 GHz
Beam Width: 10° V
Cable Length: None
Dimensions: 19.5 in. x 7/8 in. diameter (49.5 cm x 2.22 cm)
Weight: 0.45 lbs. (0.20 kg)
Operating Temperature: -30° to +70 C |
| AIR-ANT5175V-N Description: 7.5 dBi omnidirectional antenna for 5 GHz
Application: Omnidirectional antenna suitable for use on Cisco Aironet 1500 Series Lightweight Outdoor Mesh Access Points in all deployments.
Gain: 5 GHz bands = 7.5 dBi 4.9 GHz bands = 6 dBi
Frequency: 4.9-5.8 GHz
Beam Width: 16°V
Cable Length: 1 ft (0.30 m)
Dimensions: 11.65 in. x 1 in. (29.41 x 2.54 cm)
Weight: 0.38 lbs. (0.17 kg)
Operating Temperature: -30° to +70 C |
| AIR-ANT5180V-N Description: 8 dBi direct mount omnidirectional antenna for 5 GHz
Application: Omnidirectional antenna for Cisco Aironet 1520 series mesh access points. Suitable for all deployments, including cable strand mount applications.
Gain: 8 dBi
Frequency: 4.9-5.8 GHz
Beam Width: 16° V
Cable Length: None
Dimensions: 11 in. x 1 in. (27.94 x 2.54 cm)
Weight: 0.4 lbs. (0.18 kg)
Operating Temperature: -30° to +70 C |
| AIR-ANT5114P-N Description: 14 dBi wall/mast mount articulating patch antenna for 5 GHz
Application: Recommended for medium range point to point deployments
Gain: 14 dBi
Frequency: 4.9-5.8 GHz
Beam Width: 25° H, 29° E
Cable Length: 1 ft. (0.30 m)
Dimensions: 4 1/8 in. x 4 1/8 in. (10.48 cm x 10.48 cm)
Weight: 0.70 lbs. (0.32 kg)
Operating Temperature: -30° to +70 C |
| AIR-ANT5117S-N Description: 17 dBi, 90 degree mast mount sector antenna for 5 GHz
Application: Recommended for point-to-multipoint deployments of medium to long range.
Gain: 17 dBi
Frequency: 4.9-5.8 GHz
Beam Width: 90° H, 8° E
Cable Length: None
Dimensions: 24 1/2 in. x 2 ½ in. (62.23 cm x 6.35 cm)
Weight: 1.95 lbs. (0.88 kg)
Operating Temperature: -30° to +70 C |
|
